WR60X31522 WR50X10071 Refrigerator Fan Motor & Def. Thermostat Replacement for GE / Hotpoint

(No reviews yet) Write a Review
SKU: APNWR60X31522-0071_KIT
CONDITION: New
$61.58
$37.25
(You save $24.33 )
Compatible Brands:
GE
Compatible Brands:
Hotpoint

Replacement evaporator fan motor and defrost thermostat used for some GE and Hotpoint refrigerator models.

Directly Replaces: WR60X31522, WR60X10045, WR60X10046, WR60X10072, WR60X10138, WR60X10141, WR60X10346, WR60X23584, WR60X27646, WR60X28783, WR60X28784, WR60X31122, WR60X31523, 4959523, AP6977246, EAP12741350, PD00062864, PS12741350, WR50X10071, WR50X10021, WR50X10076, WR50X22303, WR50X22304, WR50X30071, SL10071, 1170027, AH1155320, AP3884319, EA1155320, EAP1155320, PD00030568, PS1155320.

Features:

  • Thermostat monitors the evaporator temperature and once the temp reaches a set point it activates warming to defrost the evaporator; Evaporator fan motor pulls air through the evaporator coils to remove heat from the circulating air within the unit.
  • Defrost Thermostat: L64-41F: Open: 64 Degree, Close: 23 Degree, 41 Degree Diff.
  • Evap motor uses a two pin connector plus ground wire.
  • Includes (1) Evaporator Fan Motor with Harness and Plug, (1) Defrost Thermostat with Tube Mount Clip and Wire Leads.

APNWR60X31522 Evaporator Fan Motor Specifications:

  • Color: Marbled White & Gray / Gray.
  • Material: Plastic / Metal.
  • Electrical Specs: 115V, 60Hz x 3.3W.
  • Dimensions: 3-1/4"L x 2-3/8"W x 3-3/8"H.
  • Additional Dimensions: Harness and plug extend 3-1/2" from motor.

APNWR50X10071 Defrost Thermostat Specifications:

  • Color: Orange / Yellow / Gray.
  • Material: Metal / Plastic.
  • Thermostat Dimensions: 1-1/16"L x 1-1/16"W x 1-1/16"H.
  • Additional Dimensions: Wire leads extend approx. 15" from thermostat.
